The VORTICE Vario range comprises manual and automatic version unidirectional and reversible axial fans, designed for wall or glass installation in domestic or commercial premises subjected to heavy-duty daily use. In this article, we look at the key features, the versions available, as well as the technical features of the Vortice Vario range.

This is part four of four covering Vortice wall and window axial fans.

The Vortice Vario range. All images supplied by Vortice

Key features

  • Wide range of possible alternative installations (windows, walls, false-ceilings, roofs, dark rooms, etc.) thanks to the optional accessories available.
  • Easy, fast installation.
  • Elegant, “Intel Design” and “Design Index Adi” award-winning design.
  • Suitable for bathroom installation.

Version

7 models, with nominal diameter between 150mm and 300mm, in unidirectional and reversible versions, driven by bushing and bearing motors, with manual and automatic drive closing fins.

Technical features

  • White, shock-proof, plastic resin (ABS) panels, prevents ageing caused by exposure to sunlight (“UV resistant”).
  • Heat protected motors with shafts mounted on bushings with self-centring and self-lubricating neck to favour low sound emissions, or on ball bearings (LL models) to ensure long-lasting (at least 30 000h) continuous service at the maximum plate temperature. Speed adjustment using VORTICE accessory devices. The direction of rotation can be reversed (R models) to perform the double function of extracting stale air and introducing fresh air into the serviced room.
  • Axial impellers moulded in plastic resin, resistant to aggressive agents, with saber shaped blades to combine high performance with low noise emissions.

    Application.

  • Exhaust duct closing fins to prevent unwanted inflows of air and bad odours when the device is switched off, automatic drive on A models.
  • Possibility of combining with a timer and temperature, relative humidity, smoke and presence sensors (optional).
  • Fully compliant with Reg. No. 327/2011/EU.
  • Performance and safety certified by third party body (IMQ) Protection rating from dust and water: IPX4.
  • Class of electric isolation: II 🞕 (earthing not required)

Read more about the product here: vortice_vario_ar_ll_s.pdf
